S355J2+N High Tensile Structural Steel Plate, Carbon Steel EN 10025 S355J2+N Sheet, Mild Steel S355J2+N Sheet, Carbon Steel S355J2+N Hot Rolled Plate, Carbon Steel S355J2+N Slatting Sheets Manufacturer in India.
Jade Special Metals is one of the finest recognized exporters of EN 10025-S355 J2+N SHEETS / PLATES, which is a kind of alloy by means of having a threaded hole. These EN 10025-S355 J2+N Sheets are more or less for all the time used opposite as a mating bolt to tie up a heap of components as one. The two collaborators are kept collectively in EN 10025-S355 J2+N Plates by a mixture of their threads' resistance, a small elongate of the bolt, and firmness of the components. In appliances where rotation or vibration may perhaps work a nut loose in EN 10025-S355 J2+N Coils, different locking devices may possibly be in work: Safety pins or lockwire, Adhesives, Nylon inserts, or oval-shaped threads to some extent.
Table of Contents
- Carbon Steel EN 10025 S355J2+N Sheets & Plates Specification
- Carbon Steel en-10025-s355j2-N Sheets & Plates Equivalent Grades
- EN 10025 S355J2+N Sheets & Plates Chemical Composition
- EN 10025 S355J2+N Carbon Steel Sheets & Plates Mechanical Properties
- Carbon Steel S355J2+N Sheets & Plates Types
- Other Types of Carbon Steel S355J2+N Sheets & Plates in Stock
- Carbon Steel S355J2+N Sheets & Plates Thickness Chart
- EN 10025 S355J2+N CS Sheets & Plates Weight Per Square Meter
Offshore S355J2+N Sheets, Structural Steel 10025 S355J2+N Plates, S355J2+N Steel Plates, High Tensile S355J2+N Steel Plates, Hot Rolled S355J2+N Sheet Supplier in Mumbai, India.
Get a best quote for ANSI B16.11 Carbon Steel EN 10025 S355J2+N Sheets from Leading Manufacturer, Buy CS S355J2+N Plates at Best Price in India.
EN 10025-S355 J2+N Slatting Sheets is a structure of threaded alloy by means of having an exterior male thread. These EN 10025-S355 J2+N Slatting Plates are therefore very much related to, and time and again confused with, screws. EN 10025-S355 J2+N Slatting Coils are also used as an extensive range of head designs, as do screws. Meanwhile, these EN 10025-S355 J2+N Perforated Sheets are being designed to connect in the company of the tool that is being used to constrict them. EN 10025-S355 J2+N Perforated Plates leads as substitute locks the bolt in position, so that it doesn’t shift and a tool is merely required for the nut end.
Carbon Steel EN 10025 S355J2+N Sheets, Plates & Coils Specification
| Standard | EN 10025-2:2004 |
|---|---|
| Material | En-10025-2 Steel Plate , S355 J2+N Steel Plate |
| Dimension | AISI, ASTM, BS, DIN, GB, JIS |
| Width | 1000mm – 3000mm |
| Thickness | 5mm - 150mm |
| Length | 3000mm -18000mm |
EN 10025 S355J2+N Carbon Steel Sheets & Plates Equivalent Grades
| Grade | DIN | EN | JIS | ASTM |
| EN 10025 S355J2+N | 17100 St52-3N |
10025-2:2004 S355J2+N |
G3106 SM490YB |
A572-50 |
EN 10025 S355J2+N Carbon Steel Sheets & Plates Chemical Composition
| Grade | C | Mn | Si | P | S | Cu | CEV |
| S355J2+N | 0.22 max. | 1.60 max. | 0.55 max. | 0.035 max. | 0.035 max. | 0.55 max. | 0.47 max. |
Mild Steel EN 10025 S355J2+N Sheets & Plates Mechanical Properties
| Thickness (mm) | Yield Strength Rehmin (N / mm²) | Tensile Strength Rmmin (N / mm²) | Elongation A5 min(%) | Impact Values Charpy-V-Notch Longitudinal Average from 3 Speimens Thk.>10 < 150mm. |
| 3<thk<100 | 355-550 | 490-630 | max 22 | 27 Joules at -20 C |
Carbon Steel EN 10025 S355J2+N Sheets & Plates Types
Carbon Steel EN 10025 S355J2+N Sheets
Carbon Steel EN 10025 S355J2+N Plate
Carbon Steel EN 10025 S355J2+N Slatting Coils
Carbon Steel EN 10025 S355J2+N Slatting Sheets
Other Types of Carbon Steel EN 10025 S355J2+N Sheets & Plates in Stock
|
|
Carbon Steel EN 10025 S355J2+N Sheets & Plates Thickness Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
|---|---|---|---|---|---|---|
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Carbon Steel EN 10025 S355J2+N Sheets & Plates Weight Per Square Meter
| Size (mm) | Weight per Sheet (Kg) |
Size (mm) | Weight per Sheet (Kg) |
|---|---|---|---|
| 2000 x1000 x 0.7 | 11.5 | 2500 x 1250 x 1.5 | 38.4 |
| 2500 x1250 x 0.7 | 17.9 | 3000 x 1500 x 1.5 | 55.3 |
| 2000 x1000 x 0.9 | 14.7 | 2000 x 1000 x 2.0 | 32.7 |
| 2500 x1250 x 0.9 | 23.0 | 2500 x 1250 x 2.0 | 51.2 |
| 2000 x1000 x 1.0 | 16.4 | 3000 x 1500 x 2.0 | 73.7 |
| 2500 x1250 x 1.0 | 25.6 | 2000 x 1000 x 2.5 | 40.9 |
| 3000 x1500 x 1.0 | 36.8 | 2500 x 1250 x 2.5 | 63.9 |
| 2000 x1000 x 1.2 | 19.6 | 3000 x 1500 x 2.5 | 92.1 |
| 2500 x1250 x 1.2 | 30.7 | 2000 x 1000 x 3.0 | 49.6 |
| 3000 x1500 x 1.2 | 44.2 | 2500 x 1250 x 3.0 | 77.5 |
| 2000 x1000 x 1.5 | 24.6 | 3000 x 1500 x 3.0 | 112.0 |
